تفاصيل المنتج:
|
|
| مكان المنشأ: | الصين |
|---|---|
| اسم العلامة التجارية: | Glawall |
| إصدار الشهادات: | SGS, ISO 9001,UL, CE |
| رقم الموديل: | الجدار الزجاجي المزدوج المعيار بالكامل |
| الوثيقة: | 25mm.pdf |
|
شروط الدفع والشحن:
|
|
| الحد الأدنى لكمية: | 10 أمهات مربعة |
| الأسعار: | US$80.00 10 - 99 square meters |
| تفاصيل التغليف: | الخشب الرقائقي |
| وقت التسليم: | 20-25 يومًا |
| شروط الدفع: | L/C ، D/A ، D/P ، T/T ، Western Union |
| القدرة على العرض: | 3000 متر مربع شهريا |
|
معلومات تفصيلية |
|||
| ميزة: | سعر تنافسي، خدمة جيدة، احترافية عالية، ضمان الجودة | مكان Origi: | قوانغدونغ ، الصين |
|---|---|---|---|
| شهادة المصنع: | نعم | منطقة مصنع: | 20000 متر مربع |
| مادة: | هيكل من الألومنيوم، ألواح صوتية | عزل الصوت: | 38-45DB |
| سمك اللوحة: | 60 ، 90.108mm | نوع الزجاج: | زجاج مقسى قوي |
| تهوية: | نظام تدفق الهواء | ضمان: | سنتان |
| إبراز: | 90mm aluminum partition wall,double glass modular partition,aluminum frame partition system,double glass modular partition,aluminum frame partition system |
||
منتوج وصف
| Advantage | Competitive price, good service, high professional, quality guarantee |
| Place of Origin | Guangdong, China |
| Factory Certification | Yes |
| Factory Area | 20000 square meter |
| Material | Aluminum Frame, Acoustic Panels |
| Soundproofing | 38-45dB |
| Panel Thickness | 60, 90, 108mm |
| Glass Type | Strong tempered glass |
| Ventilation | Airflow System |
| Warranty | 2 Years |
| Feature | Benefit |
|---|---|
| Pre-Assembled Double Glass Panels | Complete 5+5mm glass panels with integrated frame - no on-site assembly |
| Plug-and-Play Channels | Simple installation with top/side/bottom aluminum tracks |
| Tool-Free Connection | Patented click-lock system secures panels without tools |
| Fast Installation | 2-person team can install 20m² in under 3 hours |
| 42dB Soundproof Rating | 10mm air gap effectively blocks office noise |
| Thermal Insulation | Reduces HVAC costs by maintaining stable temperatures |
| Step | Action |
|---|---|
| Step 1 | Install aluminum tracks (ceiling/floor/sides) using laser level |
| Step 2 | Slide pre-assembled glass units into steel keel - no heavy lifting required |
| Step 3 | Snap decorative covers over joints for perfect alignment |
| Feature | Specification |
|---|---|
| Frame | 90mm powder-coated aluminum (20+ RAL colors) |
| Glass | 5+5mm tempered (clear/frosted/tinted options) |
| Acoustics | 42dB Rw (upgradable to 48dB with laminate) |
| Fire Rating | EI30-EI60 available |
| Max Height | 4m without additional support |
| For Contractors | For Clients |
|---|---|
| 70% faster installs = more projects per year | Immediate usability - No waiting for paint/drywall to cure |
| 50% less labor cost vs traditional systems | Adaptable layouts - Reconfigure teams without construction |
| No construction waste - LEED points achievable | Premium aesthetics - Sleek, modern appearance |
