تفاصيل المنتج:
|
|
| مكان المنشأ: | الصين |
|---|---|
| اسم العلامة التجارية: | Glawall |
| إصدار الشهادات: | SGS, ISO 9001,UL, CE |
| رقم الموديل: | مخصصة جدار قسم الألومنيوم مزدوج |
|
شروط الدفع والشحن:
|
|
| الحد الأدنى لكمية: | 10 أمتار مربعة |
| الأسعار: | US$80.00 10 - 99 square meters |
| تفاصيل التغليف: | حزمة خشبية |
| وقت التسليم: | 2-3 أسابيع |
| شروط الدفع: | L / C ، D / A ، D / P ، T / T ، ويسترن يونيون |
| القدرة على العرض: | 3000 متر مربع شهريا |
|
معلومات تفصيلية |
|||
| المواد: | إطار من الألومنيوم + لوح زجاجي | الشفافية: | واضحة |
|---|---|---|---|
| قابلة للتخصيص: | الحجم، الملحقات | سعر تنافسى: | نعم.. |
| سمك الزجاج: | 5 مم ، 8 مم ، 10 مم ، 12 مم ، صلبة | نوع الزجاج: | زجاج مقسى قوي |
| مواد الإطار: | الألومنيوم | الميزة: | سعر تنافسي، خدمة جيدة، احترافية عالية، ضمان الجودة |
منتوج وصف
Glawall Double-Glass Partition System – Technical Specifications
Premium Architectural Glass Walls for Modern Spaces
Designed for offices, conference rooms, and high-traffic areas requiring transparency + superior acoustics.
1. Core Specifications
| Parameter Specification |
| Glass Construction Double-layer tempered safety glass (5+5mm or 12+12mm) |
| Wall Thickness 79mm / 90mm / 108mm systems available |
| Max Height <3,200mm (custom heights with structural reinforcement) |
| Frame Profile Slim 35mm/40mm aluminum or stainless steel |
| Glass Connection Near-invisible joints: acrylic tape / metal strips / crystal beading |
| Acoustic Performance Rw 40-48dB (upgradable to 50dB with laminated glass) |
| Sound Absorption >0.9 NRC (optional perforated metal or 3D fiber panels) |
2. Key Features
| ✔ Seamless Aesthetic | Frameless glass-to-glass connections (1-3mm visible joint) |
| Ultra-slim 35-40mm profiles for minimalist elegance | |
| ✔ Advanced Acoustics | 12+12mm glass + air gap for STC 48 performance |
| Optional sound-absorbing cores (3D polyester fiber) | |
| ✔ Privacy & Light Control | Integrated 16mm/25mm aluminum louvers (manual or motorized) |
| Switchable PDLC glass (instant privacy) | |
| ✔ Structural Innovation | Height-adjustable frames (±15mm tolerance compensation) |
| Seismic-compliant designs available |
3. Configuration Options
| A. System Types | Model Best For | 79mm Frame (5+5mm) Budget-friendly divisions |
| 108mm Panoramic (12+12mm) Premium executive offices | ||
| 90mm Acoustic (5+5mm) Meeting rooms & call centers | ||
| B. Door Solutions | Glass pivot/sliding doors (frameless or aluminum-framed) | |
| Solid wood/steel doors (fire-rated options) | ||
| Hybrid glass+panel designs | ||
4. Performance Advantages
5. Ideal Applications
| Corporate HQs | (open-plan offices, boardrooms) |
| Healthcare | (private consultation rooms) |
| Luxury retail | (display partitions) |
| Education | (quiet study zones) |
| Technical Comparison | Glass Thickness |
| Glass Type Weight (kg/m²) Soundproofing Best Use | |
| 5+5mm 24 STC 40 General office spaces | |
| 12+12mm 56 STC 48 High-noise environments |
Why Professionals Choose This System?
The beautiful design is particularly suitable for offices, corridors, around the core tube, conference rooms, exhibition halls and other areas.
| Basic parameters: | |
| Panel thickness: | double-layer 12+12mm, 5+5mm tempered safety glass; |
| Wall thickness | 3mm |
| Glass wall height | <3200mm |
| Frame profile height | 40mm, 35mm; |
| Glass connection | transparent acrylic tape, metal ultra-narrow strip, crystal bead; |
| Sound insulation parameters | 40-48dB; |
| Sound absorption coefficient | >0.9 (perforated metal sound-absorbing panels, 3D polyester fiber sound-absorbing panels can be configured) |
| Optional models | 79mm frame double glass 5+5mm glass, 79mm frame panoramic double glass 12+12mm glass, 90mm frame double glass 5+5mm glass, 108mm frame single glass 5+5mm glass, 108mm frame double glass panoramic 12+12mm glass |
| Door type | single glass door, framed single and double glass door, wood grain/solid color steel door (multiple color cards available), double glass shutter glass door, double glass hidden frame door, wooden door, sliding door. |
| Product features |
Fully transparent double-layer glass structure, frameless connection between glass panels, fun and simple lines, 3mm frame, height adjustment function, extraordinary sound insulation performance to meet the ultimate quiet requirements. |
[Contact our engineers for custom configurations]
Glawall – Redefining spatial boundaries with light and innovation.
